An antenna diplexer or RF diplexer is a unit or module that enables two antenna feeds to be combined and carried down one feeder. Conversely, it can act as a splitter to enable the signal from one feeder to be connected to two receivers or antennas.

Tetra 400 / Mobile Diplexer

Diplexer 400 Tetra / Mobile

• Tetra and mobile antenna diplexer enables Tetra security and Mobile Cellular radio signals to be combined or split with a single feeder.
• Enabling multiple transmitters to use a single antenna: Mobile services often use multiple frequencies, possibly for different Mobile Network Operators. In view of the size and cost of the antennas they may have a single antenna and they may want to combine the signals from several transmitters to feed into the antenna. As they are on different frequencies, it is possible to use a diplexer to combine the signals and use a single feed.
• Enabling a multiband transmitter to use different antennas according to frequency.
• Allowing single feeder to be used for multiple feeds. The signals from he antennas can be combined at the antenna end using diplexer, and a second diplexer at the point of use to route the signals.
• More new products for 5G: http://www.inbuildingprojects.com/?p=909

Conceptual Diagram of a Diplexer

#4G #5G #wireless #mobile #rf #radiofrequency #das #inbuilding #inbuildingwireless #inbuildingcoverage

Outdoor Omni Antenna for Security Networks

Our monopole antenna for Tetra 400 / 800 and Trunk Radio Systems.  These are ideal for outdoor sites, BTS and oDAS. They withstand wind loading and are very durable and stable in performance.

Datasheet

Detail specifications are here:

 DTQJ400B Outdoor Omni Antenna (for Tetra 400 and Trunk Radio)

 DTSD656D54DF Outdoor Omni Antenna (for Tetra 800 / CDMA / GSM)

Quotation & Further Details

We focus on high quality and competitive products,  do like our page so we can keep you updated of our products and services, ask for a quotation here:

www.facebook.com/dragontechglobal

New high quality circulators in our family helps you get the most out of your Distributed Antenna Systems.

Stable Performance under different temperature
High performance short lead-time

For LTE 2600

2500-2700MHz

For LTE 700

745-795MHz

We have been supplying high quality circualtors for many years for:

• Any common RF bands
• Widebands

Please contact us for more details.

We have a TETRA system from Motorola which we would like to sell.

These are used by police and security forces worldwide. Some proerty management groups will use them too. These are like walkie talkie radio but they are digital and they have data communications capability.

The system we are selling has 3 cell sites and 200 subscribers. Condition is excellent.

System Overview

MTP850 Handset

If you have questions and are interested please contact us.

DragonTECH is

Sounds Long Term, LTE is really round the corner, there are already existing comemrcial networks launched and surely there will be more with new markets for high speed data driving multi-media applications like You Tube and Facebook. Let’s take a look at the challenges posted to antenna systems.

New Frequency Bands for 4G

LTE supports flexible carrier bandwidths from 1.4MHz up to 20MHz, in many spectrum bands and for both FDD and TDD.

This means an operator can introduce LTE in both new and existing bands, for example, 2.6GHz (Band 7), Advanced Wireless Service (AWS) (Band 4), or 700MHz bands.

Unlike other earlier cellular systems, LTE will be quickly deployed on multiple bands. Click here to see Verizon’s Band.

Todate, this is a broad summary (click to enlarge):

Is my DAS really ‘Future-proof’ for 4G?

This post a challenge to the existing Distributred Antenna systems (DAS) which ‘flexibly’ supports 800 – 2500 MHz. This was good enough at the 2G times, so that DAS deployed back then are ‘future-proof’ for 3G systems.

It worked well until now.

4G will now definitely spread from 700 to 2700 MHz, rendering the existing DAS system vulnerable should the local regulator mandates the use of 700 or 2600MHz.

Challenges for RAN (Radio Access Network)

For the Network Operators, your mobile subscribers are adopting 3G services but the traditional 2G subscriber base keeps growing too. You face the need to expand both network layers for more capacity and coverage to improve both the quality of service and availability. And with the onset of LTE, you must further develop your networks and rationalize your investments to deliver profitable services.

All these calls for a Converged RAN that can support from 700MHz to 2700MHz.

DragonTECH has a solution

As an industry leader, DragonTECH has developed a series of  RF components and antenna to resolve this issue. These can be used for any DAS build for 2G / 3G now and the customer is ensured a smooth upgrade path to 4G in the very near future.

Contact us for more details.

Thanks for your support. Our Service Geographics has been ever expanding. We just updated our service  coverage map. I would like to post it here to tell you how much DragonTECH appreciated your friendship and support.

Service Geographic Coverage

We will give you Spliiters with Jumper Cables Affixed!

We have a new series of Power Dividers that comes with the necessary Jumper Cables. The length and connectors can be customised.

This alleviates a lot of connections on site for a faster and easier implementation. In cases where clients are charged according to the BoQ this new idea greatly reduceds install cost.

We can customise Jumper Cables and RF components for you.

Check it out on our Products page.

Tower Mounted Amplifier & Tower Mounted Booster

TMA & TMB

DTTMAB09-18-21

DragonTECH Tower Mounted Booster together with micro base station gives macro base station coverage with minimised investments. The result is lower infrastructure cost per square kilometre.

More Details…

DragonTECH strives to be more easily accessible to the market. We participate the recent exhibition in Shenzhen, featuring the top vendors in the optical field.

The China International Optoelectronic Exposition (CIOE) is a worldwide renowned exhibition, which presents the most advanced optoelectronic technologies and innovations. The CIOE 2009 expects around 2,100 exhibitors to showcase products on 70,000 sqm from September 6-9. During the four days, more than 85,000 professional visitors will attend the exhibition. It is supported by all relevant Chinese government bodies, scientific academies, trade associations, and by domestic as well as international key players of the industry。

LED Display

Stunning effects

Exhibition booth

Its a more complex RF world.

Quadplexer with 2 antenna outputs:

We are seeing more and more combined sites with multi operators. Apart from our POIs, we offer our diplexer, triplxer and now Quadplexers for both antenna site combining and also for use as POI.

Various options are available for Tetra 400 or 800 / GSM / DCS / CDMA / WCDMA.

Two versions are available:

• Low loss High performance
• Economic with slightly higher loss

Quadplexer GSM DCS WCDMA Tetra 410

Quadplexer CDMA WCDMA GSM+DCS

Please contact us for more details.
